Multi Beam Sensors

D5.MD.C1.P3.20 Integrated 3D Model WECO-957MD 3D protection, detected to the stereoscopic area. D5.MD.C1.P3.20 TECHNICAL PARAMETERS Number of Infra Red Diodes 32 Diode sets Response Time 61 ms relay input37ms transistor output Scanning Beams 154-94 Beams Infrared Diodes Range 58.8mm Detecting Height 20-1841mm Redundancy (one transmitter shielded after 120s detected absent) ● Up/Down: ±15mm/7º Back/forth: ±3mm/5º Tolerance […]

PHOTOELECTRIC SWITCH WECO-K2 TECHNICAL FEATURES USP 13 – 30 VDC Power of Consumption Max 40mAC NPN Output Saturation Voltage NPN <1V (IL = 100mA) PNP Output Saturation Voltage PNP <2V (IL = 100mA) Response Time max 1ms Maximum Output Current 200 mA Output Mode NPN/PNP push-pull Operating Temperature -20ºC – 65ºC, 100,000LUX Protection Level IP65

Multi Beam Sensor
